LED DRIVER 65W 24V (Control mode 0/1-10V)

0 / 1-10V Dimmbare LED Profiltreiber 24V / 65W / IP40

Für 7380/9086 Profilsysteme (eingebauter Treiber)

HL-LPD7380-65W-24V
27 Artikel Auf Lager
Versand am Gleichen Tag
37,63 £ 53,75 £ -30%



65 Watt 0/1-10V dimmable LED Driver constant Voltage 24V 65W, Built-in 3 In 1 Dimming Function(0/1-10V, PWM Signal or Resistance) for 7380/9086 modular Profile systems series.

Can be used to DIM 24 Volts LED strips using 0-10V dimmer switches/signal.

Can also be used with smart home controllers as a part of a home automation to dim LED strip Lighting or other constant voltage LED products.

This is a dual function dimmable LED driver and can be controlled with both 0-10V & 1-10V dimming systems.

Characteristics:

Installation: Built-in (For HL-7380 and HL-9086 LED profiles only)

Dimming control: 0/1-10V, resistance or PWM

Input Voltage: 100~277V AC

Output Voltage: 24 Volts DC (PWM), 65W / 2.71 Amps

Dimensions: L 36.4cm x W 3.7cm x H 2.3cm

IP Rating: IP40 (non-waterproof)

Weight: 0.420 kg

Warranty: 3 Years

Betriebsspannung
24V DC
Leistung (W)
65 W
Schutzklasse (IP)
IP40 (Non-waterproof)
Type
Dimmbar 0-10V
Spannungsart
Konstantspannung
Warranty
3 Years
Hersteller
Hi-Line
