T Shape 3000K module slimline linkable under cabinet light CRI 90

HL-UCL-T-WW

New product

T Shape module 3000K CRI>90

12.5x13.5x65mm

To be used with Linkable under cabinet lighting

Mehr Infos

15 Artikel

£ 37,96

Auf meine Wunschliste

Technische Daten

LED-Chip SMD 2216
Leuchtfarbe Warmweiß
Betriebsspannung 24V DC
Schutzklasse (IP) IP20 (Nichtwasserdicht)
Weißfarbtemperatur (CCT) 3000K
Farbwidergabeindex-CRI-ra Ra - mehr als 90
Spannungsart Konstantspannung
Module built-in driving method Constant Current
Warranty 3 Years
Hersteller Hi-Line

Mehr Infos

T Shape module slimline linkable under cabinet light warm white 3000K - CRI 90

Dimensions: 12.5 x 13.5 x 65mm

Modular Design - No Soldering - No cutting - No DIY wiring - Ready to use Mini LED Aluminium profile modules without spotting

Note: This product is rated at 24V DC, additional power supply is required. You can power up to 10 linear meters in series connection (one power lead to be installed at any of the 2 ends of the circuit). Power connector lead should be purchased separately.

Optional Linear lengths 3000 or 6500K (available to buy separately):

100mm slim linear profile batten 24V/1W/65lm W12.5 x H13.5mm - 24 Epistar LEDs CRI>90 - IP20
192mm slim linear profile batten 24V/2W/130lm W12.5 x H13.5mm - 42 Epistar LEDs CRI>90 - IP20
285mm slim linear profile batten 24V/3W/195lm W12.5 x H13.5mm - 66 Epistar LEDs CRI>90 - IP20
565mm slim linear profile batten 24V/6W/390lm W12.5 x H13.5mm - 132 Epistar LEDs CRI>90 - IP20
845mm slim linear profile batten 24V/9W/580lm W12.5 x H13.5mm - 198 Epistar LEDs CRI>90 - IP20
1123mm slim linear profile batten 24V/12W/750lm W12.5 x H13.5mm - 264 Epistar LEDs CRI>90 - IP20

Optional LED modules 3000 or 6500K (available to buy separately):

L-Shape plug and play LED module 12.5 x 13 x 65mm
X-Shape plug and play LED module 12.5 x 13 x 65mm
T-shape plug and play LED module (same as this product listing but in cool white 6500K)

Plug and Play connectors (available to buy separately):

Seamless 180 degrees connector joint 41 x 7.5mm
Power connector with cable 26.5 x 7.5mm
Extension cable connector 26.5 x 7.5mm

Ideal for kitchen units, pelmets furniture, open plan offices, classrooms, corridors and retail premises

3 years Warranty
