D4-L DMX512 RGBW LED Controller | 4-Channel Constant Voltage

A versatile, high-performance 4-channel constant voltage controller for professional LED lighting. It supports RDM for remote management, advanced dimming with 8-bit and 16-bit grey scales, and multiple dimming curves. The controller handles up to 5A per channel, with a recommended total current of 13A for optimal performance. Standalone RGB/RGBW modes and robust design ensure reliable operation. Ideal for installations requiring precise control and flexibility.

Important Product Details

  • optional 250 char. max
HL-D4-L
20 Items In stock
Next working day delivery
£29.50
35.40
with VAT)



The D4-L DMX512 LED Controller is a versatile and high-performance 4-channel constant voltage controller, perfect for professional LED lighting installations. It fully complies with DMX512 standard protocols and includes RDM (Remote Device Management) for easy communication and configuration between the DMX master and decoder.



Key Features:

Supports 1, 2, or 4 DMX channel outputs.

Offers 16-bit (65536 levels) and 8-bit (256 levels) grey scales, with PWM frequency settings from 250Hz to 16000Hz for smooth, flicker-free dimming.

Provides multiple dimming curves, both logarithmic and linear, for fine-tuning light output.

Operates in standalone RGB/RGBW and dimmer modes, even without a DMX signal, making it suitable for independent installations.

Robust design with a wide operating temperature range (-30°C to +55°C) and features overheat and short circuit protection with automatic recovery.



Usage and Installation Note:

While each channel can handle up to 5A, high current loads can increase the device's temperature. It is recommended to limit the total current across all channels to around 13A with adequate ventilation. Professional installers often load the controller at about 50% capacity to maintain lower temperatures and extend its operational life.



Specifications:

Input Voltage: 12-24VDC

Output Voltage: 4 x (12-24)VDC

Output Current: 4CH, 5A/CH

Output Power: 4 x (60-120)W

IP Rating: IP20

Safety & EMC: Certified to CE, EMC, LVD, and UKCA standards



For professionals seeking enhanced lighting control, the D4-L DMX512 LED Controller offers a powerful blend of performance, flexibility, and ease of use.



Looking for Related Products or Accessories?

Discover compatible products and accessories by clicking the 'Related Products' tab at the top of this product description on desktop, or just after this section on mobile devices. For detailed specifications, the 'Product Specification' tab is also available at the top of this description, offering immediate access to important product details. If you need technical data or installation guides, the 'Attachments' tab is located in the same area. To refine your search within any product category, the "REFINE BY" filter system is positioned on the left side of the screen on desktops and at the top of the page on mobiles, ensuring a seamless browsing experience.

Brand
Hi-Line
Resolution
8-Bit
16-Bit
Type
RGB/RGBW controller
Voltage Type
Constant Voltage
Type of control
DMX512
Warranty
5 Years
