LED SIGNAGE

Hi-Line's LED Signage Lighting Systems enable infinite signage applications for indoor and outdoor sign lighting manufacturers. Our products provide significant energy savings and easy installation. Our long-life LED systems deliver exceptional performance for channel letter, and backlit or edge light sings applications. All signage LED products come with 5 Years Warranty.

1
2

LED Edge lightbox

LED Edge lightbox 2

Next working day delivery

LED EDGE LIGHTING

Osram LED Edge lightbox module | 24V | 15W | 6000K | 15°*45° | IP65

Hi-Line Lighting

Ideal for lightbox signage, or wall washer 8-30cm depth single or 15-30cm double sided lightbox Maximum lightbox height for optimum results 2.5-3m Suitable for tension graphics and bespoke light boxes Accessories must be purchased separately Power: 24V / 15W Colour Temperature (CCT): 6000K Elliptical lens, beam angle 15x45° IP Rating: IP65

LED backlight module tape 12V 0.72W 55Lm white 7000K 170° IP65

LED backlight module tape 12V 0.72W 55Lm white 7000K 170° IP65 2

PRE-ORDER

LED BACK LIGHTING

LED backlight module tape | 12V | 0.72W | 55Lm white | 7000K | 170° | IP65

Hi-Line Lighting

Key Features: Price is for 200 modules (0.72W each) Ideal for lightboxes 3.5-10cm depth Voltage: 12V DC Module Power Consumption: 0.72W Colour Temperature (CCT): 7000K (200 modules) LED Module Beam Angle: 170° IP Rating: IP65

Osram LED signage

Osram LED signage 2

Next working day delivery

LED EDGE LIGHTING

Osram LED Edge lightbox module | 24V | 12.5W | 6000K | 15°*45° | IP65

Hi-Line Lighting

Ideal for light box signage or wall washer Suitable for tension graphics and bespoke light boxes 8-30cm depth single or 15-30cm double sided light box Maximum lightbox height for optimum results 2.5-3m Accessories must be purchased separately Power: 24V / 12.5W Colour Temperature (CCT): 6000K Elliptical lens beam angle 15x45° IP Rating: IP65

Micro Sign LED module pure white

Micro Sign LED module pure white 2

PRE-ORDER

LED CHANNEL LETTERS

Single Micro Sign LED module | Pure white | 24V | 0.24W | 7000K | IP67 (string of 40)

Hi-Line Lighting

Micro sign LED module For mini signs 2-6cm depth Module Power Consumption: 0.24w Voltage: 24V DC Colour Temperature (CCT): 7000K Colour: Pure White IP Rating: Waterproof IP67

Osram LED Edge lightbox module 24V 7.5W 7000K 15°*45° IP65

Osram LED Edge lightbox module 24V 7.5W 7000K 15°*45° IP65 2

PRE-ORDER

LED EDGE LIGHTING

Osram LED Edge lightbox module | 24V | 7.5W | 6000K | 15°*45° | IP65

Hi-Line Lighting

Key Features: Ideal for light box signage or wall washer Suitable for tension graphics and bespoke light boxes 8-30cm depth single or 15-30cm double sided light box Maximum lightbox height for optimum results 2.5-3m Accessories must be purchased separately Power: 24V / 7.5W 6000K Elliptical lens beam angle 15x45° IP Rating: IP65

Micro Sign LED module 0.48W 24V pure white 7000K IP67 (string of 40)

Micro Sign LED module 0.48W 24V pure white 7000K IP67 (string of 40) 2

LED CHANNEL LETTERS

Twin Micro Sign LED module | Pure white | 0.48W | 24V | 7000K | IP67 (string of 40)

Hi-Line Lighting

Key Features: Twin Micro sign LED module For mini signs 2-6cm depth Module Power Consumption: 0.48w Voltage: 24V DC Colour Temperature (CCT): 7000K Colour: Pure White IP Rating: Waterproof IP67

Triple Micro Sign LED module 0.72W 24V pure white 7000K IP67 (string of 40)

Triple Micro Sign LED module 0.72W 24V pure white 7000K IP67 (string of 40) 2

LED CHANNEL LETTERS

Triple Micro Sign LED module | Pure white | 0.72W | 24V | 7000K | IP67 (string of 40)

Hi-Line Lighting

Key Features: Triple Micro sign LED module For mini signs 2-6cm depth Module Power Consumption: 0.72W Voltage: 24V DC Colour Temperature (CCT): 7000K Colour: Pure White IP Rating: Waterproof IP67

Red Micro Sign single LED module 24V 0.24W 7000K IP67 (string of 40)

Red Micro Sign single LED module 24V 0.24W 7000K IP67 (string of 40) 2

Next working day delivery

LED CHANNEL LETTERS

Red Micro Sign single LED module | 24V | 0.24W | IP67 | (string of 40)

Hi-Line Lighting

Key Features: Colour: Red Micro sign LED module For mini signs 2-6cm depth Module Power Consumption: 0.24w Voltage: 24V DC IP Rating: Waterproof IP67

LED module 12V 0.72W 70Lm white 7000K 160°

LED module 12V 0.72W 70Lm white 7000K 160° 2

PRE-ORDER

LED CHANNEL LETTERS

LED Channel letter module | 12V | 0.72W | 70Lm white | 7000K | 160° | IP65

Hi-Line Lighting

Key Features: Pack of 100pcs Ideal for sign lighting applications 8-15cm depth Voltage: 12V DC Module Power Consumption: 0.72W Colour Temperature (CCT): 7000K LED Module Beam Angle: 160° IP Rating: IP65

170° IP68 LED module 12V 0.4W

170° IP68 LED module 12V 0.4W 2

LED CHANNEL LETTERS

LED Channel letter module | 12V | 0.4W | 44Lm white | 7000K | 170° | IP68

Hi-Line Lighting

Key Features: Pack of 150 modules Ideal for sign lighting applications 3-6cm depth Voltage: 12V DC Module Power Consumption: 4W Colour Temperature (CCT): 7000K LED Module Beam Angle: 170° IP Rating: IP68

LED module 12V 0.8W 170°

LED module 12V 0.8W 170° 2

PRE-ORDER

LED CHANNEL LETTERS

LED Channel letter module | 12V | 0.8W | 88Lm white | 7000K | 170° | IP68

Hi-Line Lighting

Key Features: Pack of 100 modules Ideal for sign lighting applications 3-6cm depth Voltage: 12V DC Module Power Consumption: 0.8W Colour Temperature (CCT): 7000K LED Module Beam Angle: 170° IP Rating: IP68

170° LED module 1.2W

170° LED module 1.2W 2

PRE-ORDER

LED CHANNEL LETTERS

LED Channel letter module | 12V | 1.2W | 130Lm white | 7000K | 170° | IP68 (90pcs)

Hi-Line Lighting

Key Features: Price is for 90 modules (3 chains x 30 modules each) Ideal for sign lighting applications 6-12cm depth Voltage: 12V DC Module Power Consumption: 1.2W Colour Temperature (CCT): 7000K LED Module Beam Angle: 170° IP Rating: IP68

LED module 170°

LED module 170° 2

PRE-ORDER

LED CHANNEL LETTERS

LED Channel letter module | 12V | 1.6W | 180Lm white | 7000K | 170° | IP68 (90 pcs)

Hi-Line Lighting

Key Features: Price is for 90 modules (3 chains x 30 modules each) Ideal for sign lighting applications 6-12cm depth Voltage: 12V DC Module Power Consumption: 1.6W Colour Temperature (CCT): 7000K LED Module Beam Angle: 170° IP Rating: IP68

LED back lighting module 12V 0.72W 55Lm white 7000K 170°

LED back lighting module 12V 0.72W 55Lm white 7000K 170° 2

Next working day delivery

LED BACK LIGHTING

LED back lighting module | 12V | 0.72W | 55Lm white | 7000K | 170° | IP68 (50 pcs)

Hi-Line Lighting

Key Features: Price is for a String of 50pcs Ideal for sign lighting applications 3.5-15cm depth Voltage: 12V DC Module Power Consumption: 0.72W Colour Temperature (CCT): 7000K LED Module Beam Angle: 170° IP Rating: IP68

7 output single side busbar for HL-S2002

7 output single side busbar for HL-S2002 2

Next working day delivery

LED BACK LIGHTING

7 output single side busbar for HL-S2002

Hi-Line Lighting

Key Features: 7 output single side "busbar" for LED tape HL-S2002

14 output double sided busbar for HL-S2002

14 output double sided busbar for HL-S2002 2

Next working day delivery

LED BACK LIGHTING

14 output double sided busbar for HL-S2002

Hi-Line Lighting

Key Features: 14 output double sided "busbar" for LED tape HL-S2002

LED backlight module 12V 1.32W 125Lm white 7000K 160° IP68

LED backlight module 12V 1.32W 125Lm white 7000K 160° IP68 2

PRE-ORDER

LED BACK LIGHTING

LED backlight module | 12V | 1.32W | 125Lm white | 7000K | 160° | IP68 (100pcs)

Hi-Line Lighting

Key Features: Price is for 100 x IP68 modules Ideal for light box 3.5-15cm Voltage: 12V DC Module Power Consumption: 1.32W Colour Temperature (CCT): 7000K (100 modules) LED Module Beam Angle: 160° IP Rating: IP68

LG LED backlight module 24V 4W 500Lm white 6500-7000K 170° IP65

LG LED backlight module 24V 4W 500Lm white 6500-7000K 170° IP65 2

Next working day delivery

LED BACK LIGHTING

24 x LG LED backlight module | 12V | 4W | 500Lm | white 6500-7000K | 170° | IP65

Hi-Line Lighting

Key Features: Ideal for light box 10-20cm Voltage: 12V DC Module Power Consumption: 4W Colour Temperature (CCT): 7000K LED Module Beam Angle: 170° IP Rating: IP65

LED backlight module 12V 7W 650Lm white 7000K beam angle 170° IP65

LED backlight module 12V 7W 650Lm white 7000K beam angle 170° IP65 2

PRE-ORDER

LED BACK LIGHTING

LED backlight module | 12V | 7W | 650Lm white | 7000K beam angle 170° | IP65

Hi-Line Lighting

Key Features: Ideal for light box 10-20cm Voltage: 12V DC Module Power Consumption: 7W Colour Temperature (CCT): 7000K LED Module Beam Angle: 170° IP Rating: IP65

LED Edge lighting light box module 12V 2.5W

LED Edge lighting light box module 12V 2.5W 2

PRE-ORDER

LED EDGE LIGHTING

LED Edge lighting light box module | 12V | 2.5W | 7000K | 15°*45° | IP68 | (60 pcs)

Hi-Line Lighting

Key Features: Ideal for single or double sided light box 8-20cm single sided lightbox 15-30cm double sided lightbox Voltage: 12V DC Module Power Consumption: 2.5W Colour Temperature (CCT): 7000K Elliptical lens beam angle: 15x45° IP Rating: IP68

Showing 1-20 of 38 item(s)
