LED Driver "Premium series" 30W 24V IP67

HL-30W-24V-IP67-5Y

New product

Premium Series LED Driver 30W/24V

Input: 85-265V AC

Output: 24V / 1.25A

Constant Voltage Type – IP67

5 years Warranty

More details

22 Items

Same Day Dispatch

£ 27,50 excl. VAT

Add to wishlist

Data sheet

Voltage 24V DC
Power 30 W
Rating IP67 (Waterproof)
Type non-dimmable
Voltage Type Constant Voltage
Warranty 5 Years
Brand Hi-Line

More info

Premium series 30W 24V LED driver - 5 years Warranty



This is a highly specified switch mode-constant voltage power supply using the best electronic components in the market.

Non dimmable LED Driver suitable for LED Strips of total power consumption up to 30W.

It is recommended to calculate 20% more that the tape power consumption for better performance of the power supply.

As an example this LED Driver can be used for up to 1.7 meters of high power single colour or RGBW LED strip (14.4W per meter X 1.20 load factor). Of course same applies for single colours LED strips that consume 14.4W per meter.

LED Driver 30W/24V

Input: 85~265V AC (50/60Hz)

Output: 24V / 1.25 Amps

Suitable for LED Strips

Rating: IP67 (Waterproof)

Power factor: >0.98

Efficiency: > 85%

Ripple: <2%

Dimensions: L151*W45*H33 mm

Weight: 382g

Warranty offered for the LED driver is 5 years

___________________________

Note that LED strips dimming is possible if this driver is used in combination with an LED controller. In such case LED driver is not required to be dimmable and brightness control (dimming) is still possible through the LED controller.

For driving RGB or RGBW LED Strips, you will have to combine the Driver with a RGB-RGBW LED Controller.

___________________________

IMPORTANT NOTICE!

This device should be installed by a qualified electrician in accordance with the latest edition of the IEE Wiring Regulations and any applicable Building Regulations.

____________________________

The table below shows the maximum LED strip length, which can be operated with this LED driver.

To consider best power supply performance 20% were deducted from the maximum strip length in the table below.

____________________________

For more information about the installation of LED Strips, you can download below PDF file: “Installation of LED Strips”.
