Very Warm White Top Bend Neon Flex 15x15mm 2200K (sold per meter)

HL-PNF-EWW-24V

New product

Top Bend Very Warm White 2200K Neon Flex

High Brightness - Premium series

24V - 15 w/m - 120 LEDs/m CRI>90

Dimensions: 15x15mm (Top Bend)

Rating: IP65/IP67

3 year warranty

More details

200 Items

Same Day Dispatch

£ 19,50

£ 19,50 per meter

Add to wishlist

Data sheet

LED Chip SMD 2835
Voltage 24V DC
Colour Very Warm White
Power 15 Watt per meter
Brightness 720 lm/m
Number of LEDs per meter 96
Rating IP65 / IP67
Colour Temperature (CCT) 2200K
Colour rendering (CRI in ra) more than 90
Height of strip 20mm
Cutting length Every 6 LEDs (50mm)
LED Neon Flex Type Flat Surface - Vertical Bending (Top)
Neon Flex Width 15mm
Neon Flex Height 15mm
Voltage Type Constant Voltage
LED Neon Flex Beam Angle 160 Degrees
Warranty 3 Years
Brand Hi-Line

More info

Top Bend Very Warm White Silicone LED neon flex 2200K CRI>90 - 24V IP65/67- 15x15mm (Sold per meter)


Silicone LED Neon flex powered by 2200K very warm white CRI>90 SMD2835 LED chips

15mm wide x 15mm height

Flame Retardant - UV Resistant - Salt water resistant - Solvent resistant

Suitable for installations on yatchs, facade lighting, indoor and outdoor projects.

Flat design for architectural lighting (Top Bending). Sits flush along edges and provides a 160 degree beam angle.

15 W/m – 24V DC – 120 LEDs/m – IP65/67 – 2 wire - Silicone

CCT 2200K, light output >700 lm/m

LED Neon flex can be cut at every 5 cm (50mm)

Please Note: Minimum order is for 1 Metre length. If you order more than a 1 Metre length of Neon Flex you will receive a continuous run as it is taken from a 50m roll.

Also, if connectors are required, these need to be purchased separately. You will only receive tail ends when you purchase a 50m roll. Connection Kits for 15x15mm Flex require soldering.

If purchasing a 50 metre roll, please do not test the entire length - you will risk burning out the pcb / chips.

3 year warranty
IP67 rating is subject to correct installation



The high quality of Hi-Line LED Neon flex products ensures low decay, which increases the LED's lifespan and assures that the level of the brightness is kept constant throughout the LED's estimated life.

Please do NOT connect more than 10 meters of LED flex in series. A LED flex of more than 10 meters in length will overloaded, due to the increased amount of current passing through, resulting in the damage of the internal FCB and failure of the product. A maximum of 20m of this product can be installed in a single run only with 24V power fed from both sides in parallel. Alternatively you may power the flex (24V DC) in the middle of the run (leaving 10 meters LED flex to the left and 10 meters to the right).

_____________________________


All Hi-Line LED neon flex are PWM dimmable.
Please select a suitable PWM LED dimmer/controller to ensure the proper dimming of the product.

LED neon flex is fully compatible with Lutron, Fibaro, Rako or ANY conventional constant voltage LED controller available on the market. We do also offer a wide range of single colour LED controllers including wireless, DMX512, ZigBee, DALI and and 0/1-10V to choose from.

______________________________

The stated price is for 1m Silicone LED Flex in very warm white (2200K) powered by 120 x SMD2835 LEDs – IP65/IP67, 24V DC.

______________________________



Selection of the LED driver (LED switch mode power supply) depending on the maximum LED Neon Flex length

To consider best power supply performance, we suggest using 20% higher capacity (Wattage) of what the rated power consumption of neon flex will be.

Note: for driving single colour LED neon flex, you just need the flex, power connector and LED driver. If dimming is required you will have to combine the LED-Driver with a single colour LED dimming controller. In such a case, the LED driver is not required to be dimmable. Brightness control (dimming) and colour adjustment is still possible through the controller.

For further assistance, please visit out support page or contact us.
