24V 200W Constant Voltage LED Driver IP67 (EC Series)

IP67 LED Driver 200W/24V

Suitable for LED Strips

Input: 170~250V AC (50/60Hz)

Output: 24V / 8.33 Amps

Constant Voltage Type

3 Year Warranty

HL-200W-24V-IP67-EC
Out of Stock
£43.00



High Efficiency 24 Volts Constant Voltage LED Driver 200 Watt IP67 (EC Series) - 3 Years Warranty

Non-dimmable LED Driver suitable for LED Strips of total power consumption up to 200W.

It is recommended to calculate 20% more than the tape power consumption to cover voltage drop of the circuit.

Note: This is an economy series driver. If you prefer lower in-rush current and higher power factor products, then consider our premium series drivers instead. Installers should be aware of in-rush current and the type of MCB required in such cases.

To learn more about In-rush current, visit out support page HERE

LED Driver 200W/24V Suitable for LED Strips

Short circuit and overload protection

Input: 170~250V AC (50/60Hz)

Output: 24V / 8.33 Amps

Efficiency: 90%

Rating: IP67 (Waterproof)

Dimensions: 239*61*33 mm

Weight: 844g

Warranty offered for the LED driver is 3 years

PLEASE ALSO CHECK OUT OUR 200W/24V PREMIUM LED DRIVER HERE (5 YEARS GUARANTEE)

___________________________

Note that LED strips dimming is possible if this driver is used in combination with an LED controller. In such case LED driver is not required to be dimmable and brightness control (dimming) is still possible through the LED controller.

For driving RGB or RGBW LED Strips, you will have to combine the Driver with an RGB-RGBW LED Controller.

____________________________

IMPORTANT NOTICE!

This device should be installed by a qualified electrician in accordance with the latest edition of the IEE Wiring Regulations and any applicable Building Regulations.

____________________________

The table below shows the maximum LED strip length, which can be operated with this LED driver.

To consider best power supply performance 20% was deducted from the maximum strip length in the table below.

For more information about the installation of LED Strips, you can download the below PDF file: “Installation of LED Strips”.

Voltage
24V DC
Power
200 W
Rating
IP67 (Waterproof)
Type
non-dimmable
Voltage Type
Constant Voltage
Warranty
3 Years
Brand
Hi-Line
