Non-dimmable LED Driver suitable for LED Strips of total power consumption up to 350W.
It is recommended to calculate 20% more than the tape power consumption to cover voltage drop of the circuit.
LED Driver 350W/24V Suitable for LED Strips
Input: 170~264V AC (50/60Hz)
Output: 24V / 14.58 Amps
Rating: IP67 (Waterproof)
Dimensions: 235*120*53 mm
Weight: 2.12Kg
Warranty offered for the LED driver is 2 years
Note that LED strips dimming is possible if this driver is used in combination with an LED controller. In such case LED driver is not required to be dimmable and brightness control (dimming) is still possible through the LED controller.
For driving RGB or RGBW LED Strips, you will have to combine the Driver with an RGB-RGBW LED Controller.
IMPORTANT NOTICE!
This device should be installed by a qualified electrician in accordance with the latest edition of the IEE Wiring Regulations and any applicable Building Regulations.
The table below shows the maximum LED strip length, which can be operated with this LED driver.
To consider the performance drop, which occurs in the power supply cable and the efficiency of the LED Driver, 20% was deducted from the maximum strip length in the table below.
For more information about the installation of LED Strips, you can download the above PDF file: “Installation of LED Strips”.
