LED Driver 60W/24V IP67 - EC Series

Input: 170-250V AC

Output: 24V / 2.5A

Constant Voltage Type – IP67

3 years Warranty

HL-60W-24V-IP67-EC
107 Items In stock
Same Day Dispatch
£19.00



High Efficiency Constant Voltage LED Strip Driver 60 Watt 24 Volts IP67 - EC Series

Non-dimmable 24 Volts LED Driver suitable for LED Strips or LED light box modules of total power consumption up to 60W.

It is recommended to calculate 20% more than the tape power consumption for better performance of the power supply.

Note: If you are intending to dim via controllers and remote, you may wish to consider a larger wattage driver to avoid potential buzzing issues, if for example you are running just a couple of metres of LED strip to a driver. Our 100W premium series can eliminate this.

Note: This is an economy series driver. If you prefer lower in-rush current and higher power factor products, then consider our premium series drivers instead. Installers should be aware of in-rush current and the type of MCB required in such cases.

To learn more about In-rush current, visit out support page HERE

LED Driver 60W/24V

Input: 170~250V AC (50/60Hz)

Output: 24V / 2.5 Amps

Rating: IP67 (Waterproof)

Efficiency: > 86%

Dimensions: L205 x W35 x H26 mm

Weight: 258g

Warranty offered for the LED driver is 3 years

The table below shows the maximum LED strip length, which can be operated with this LED driver.

To consider the best power supply performance, 20% was deducted from the maximum strip length in the table below.

___________________________

IMPORTANT NOTICE!

This device should be installed by a qualified electrician in accordance with the latest edition of the IEE Wiring Regulations and any applicable Building Regulations.

Voltage
24V DC
Power
60 W
Rating
IP67 (Waterproof)
Type
non-dimmable
Voltage Type
Constant Voltage
Warranty
3 Years
Brand
Hi-Line
