LED Driver | 24V | Constant Voltage | 60 Watt | IP67 | EC Series

  • LED Driver
  • 60W / 24V DC
  • IP67 - EC Series
  • Input: 170-250V AC
  • Output: 24V / 2.5A
  • Constant Voltage Type
  • IP67
  • 3 years Warranty

Important Product Details

  • optional 250 char. max
HL-60W-24V-IP67-EC
47 Items In stock
Next working day delivery
£16.00
19.20
with VAT)
VAT excluded



High Efficiency Constant Voltage LED Strip Driver 60 Watt 24 Volts IP67 - EC Series

Non-dimmable 24 Volts LED Driver suitable for LED Strips or LED light box modules of total power consumption up to 60W.

It is recommended to calculate 20% more than the tape power consumption for better performance of the power supply.

Note: If you are intending to dim via controllers and remote, you may wish to consider a larger wattage driver to avoid potential buzzing issues, if for example you are running just a couple of metres of LED strip to a driver. Our 100W premium series can eliminate this.

Note: This is an economy series driver. If you prefer lower in-rush current and higher power factor products, then consider our premium series drivers instead. Installers should be aware of in-rush current and the type of MCB required in such cases.

To learn more about In-rush current, visit out support page HERE

LED Driver 60W/24V

Input: 170~250V AC (50/60Hz)

Output: 24V / 2.5 Amps

Rating: IP67 (Waterproof)

Efficiency: > 86%

Dimensions: L205 x W35 x H26 mm

Weight: 258g

Warranty offered for the LED driver is 3 years

The table below shows the maximum LED strip length, which can be operated with this LED driver.

To consider the best power supply performance, 20% was deducted from the maximum strip length in the table below.


IMPORTANT NOTICE!

This device should be installed by a qualified electrician in accordance with the latest edition of the IEE Wiring Regulations and any applicable Building Regulations.

Looking for Related Products or Accessories?

Discover compatible products and accessories by clicking the 'Related Products' tab at the top of this product description on desktop, or just after this section on mobile devices. For detailed specifications, the 'Product Specification' tab is also available at the top of this description, offering immediate access to important product details. If you need technical data or installation guides, the 'Attachments' tab is located in the same area. To refine your search within any product category, the "REFINE BY" filter system is positioned on the left side of the screen on desktops and at the top of the page on mobiles, ensuring a seamless browsing experience.

Brand
Hi-Line
Power
60 W
IP Rating
IP67 (Waterproof)
Type
non-dimmable
Voltage
24V DC
Voltage Type
Constant Voltage
Warranty
3 Years
