12V 200W High Efficiency Constant Voltage LED Driver IP67
LED Driver 200W/12V IP67
Input: 170-250V AC
Output: 12V / 16.7A
Constant Voltage Type – IP67
3 years Warranty
12V High Efficiency Constant Voltage LED Driver 200 Watt IP67 - EC Series - 3 Years Warranty
Non-dimmable 12 Volts LED Driver suitable for LED Strips or LED light box modules of total power consumption up to 200W.
It is recommended to calculate 20% more than the tape power consumption for better performance of the power supply.
LED Driver 200W/12V
Input: 170~250V AC (50/60Hz)
Output: 12V / 16.7 Amps
Rating: IP67 (Waterproof)
Efficiency: > 90%
Dimensions: L238 x W61 x H33mm
Warranty offered for the LED driver is 3 years
The table below shows the maximum LED strip length, which can be operated with this LED driver.
To consider the best power supply performance, 20% was deducted from the maximum strip length in the table below.
This device should be installed by a qualified electrician in accordance with the latest edition of the IEE Wiring Regulations and any applicable Building Regulations.
