DALI RGB PWM Dimming Controller (XY DALI Type 8)

  • DALI DT8 LED DIMMER
  • RGB DALI Type 8 - XY Version
  • Single DALI address
  • CONSTANT VOLTAGE

Important Product Details

  • optional 250 char. max
DALI-DT8-RGB-XY
PRE-ORDER
£63.00
75.60
with VAT)

The minimum purchase order quantity for the product is 5.

Quantity Unit price You Save
30 £56.70 £189.00


Device type 8 DALI RGB-XY PWM DIMMING CONTROLLER DT8 - XY coordinates version (CT, x-y colour presentation)

DALI DT8 device to control Red, Green, Blue output via a single DALI address

This is a DALI Type 8 device that can control 3 output channels (constant voltage RGB strips) only via XY coordinates for setting the colour.

Supports DT8 device commands, compatible with DALI masters that support XY DT8 commands (XY coordinates only).

Built-in numeric digital display for setting DALI address manually.

Configurable via DALI software tool and DALI USB interface.

Important note: Not every DALI Master control device supports commands for DT8 colour control and not every DALI type 8 compatible Master device supports RGB-XY colour types (CT, x-y colour presentation).

Perfect match for all Hi-line's RGB LED strips.

  • 3 channels constant voltage common anode output
  • Input: 12 to 36 Volts DC.
  • Complies to IEC62386-209:2011
  • Output current: 3 x 5A (max)
  • Output power per channel: 12V/60Watt, 24V/120Watt, 36V/180Watt
  • Overcurrent / overheat protection
  • Enables Dimming and Color Adjustment
  • Waterproof grade: IP20
  • Size: (LxWxH) 170x53x28mm
  • 5 years Warranty

Looking for Related Products or Accessories?

Discover compatible products and accessories by clicking the 'Related Products' tab at the top of this product description on desktop, or just after this section on mobile devices. For detailed specifications, the 'Product Specification' tab is also available at the top of this description, offering immediate access to important product details. If you need technical data or installation guides, the 'Attachments' tab is located in the same area. To refine your search within any product category, the "REFINE BY" filter system is positioned on the left side of the screen on desktops and at the top of the page on mobiles, ensuring a seamless browsing experience.

Brand
Hi-Line
IP Rating
IP20 (Non-waterproof)
Type
DALI DT8 dimmable
Voltage
12-36V DC
Voltage Type
Constant Voltage
Type of control
DALI
Warranty
5 Years
