Key Features:

  • 4 in 1 dimming controller
  • 1 channel 12-36VDC output, max. 20A
  • AC push DALI Phase cut 0/1-10V
  • Dimming Range: 0-100%
  • 12 to 36V DC Input
HL-4IN1-DIM
67 Items In stock
Next working day delivery
£45.00
54.00
with VAT)
VAT excluded



4 in 1 Dimming controller for single colour LED strips, input voltage DC 12 to 36V with one output maximum 20A.

Multiple dimming modes to choose from, AC push dimmer (using press switch), Phase cut dimmer (mains dimmable) that can be used with both trailing and leading edge wall dimmers, 0/1-10V dimming input and DALI (1 DALI address).

Dimming Range: 0-100%

  • Multifunctional 4 in 1 LED Dimmer, with DALI, AC push, 0/1-10V and Phase Cut dimming interfaces

  • Dip switch to select different dimming interfaces

  • 1 channel 12-36VDC output, max. 20A

  • Supports both leading edge and trailing edge dimming input

  • Complies to DALI standards IEC 62386-102, IEC 62386-207

  • Matches with all DALI systems in the market

  • 1 DALI address assigned by DALI master

  • Compatible with any wall dimmer switch (phase cut dimmers, leading or trailing edge)

  • Works with any Dimmer switch, controller only senses dimmer output voltage so dimmer switch operates only as signalling device for the controller.

Safety Warning

DO NOT change or select dimming input with power applied to the device!

Looking for Related Products or Accessories?

Click the 'Related Products' tab below the product description to find compatible LED strips, drivers, and accessories. For technical data or installation guides, check out the 'Attachment' tab for available PDFs. To refine your search further, use our "REFINE BY" filter system available when browsing any product category.

Brand
Hi-Line
Mains Dimming
Leading or Trailing Edge
Voltage
12-36V DC
Voltage Type
Constant Voltage
Warranty
5 Years
