Microwave Motion Sensor with RF, 0-10V & Zigbee 3.0 Control
Professional microwave motion and occupancy sensor designed for intelligent lighting automation systems. Unlike basic PIR infrared sensors, this advanced microwave sensor uses high-frequency radar detection technology for improved sensitivity, wider coverage, and more reliable motion detection in commercial and residential environments.
The sensor supports RF 2.4GHz wireless control, 0-10V / 1-10V dimming output, AC relay switching, and Zigbee 3.0 communication, making it suitable for smart lighting systems, corridors, offices, warehouses, staircases, utility rooms, commercial buildings, and energy-saving lighting projects.
Compared to standard PIR infrared sensors, microwave technology provides significantly improved sensitivity and more consistent motion detection performance. The sensor can detect smaller movements more effectively, helping maintain lighting activation in occupied areas. While highly sensitive, this product should be considered a professional microwave motion and occupancy sensor rather than a specialist ultra-sensitive presence detector designed to detect breathing or completely motionless occupants.
One of the main advantages of this sensor is its flexible control compatibility. The built-in RF wireless transmission system allows the sensor to wirelessly trigger compatible RF lighting controllers and RF dimmable LED drivers without requiring additional signal wiring between the sensor and lighting controller.
This allows many different lighting systems to be automated wirelessly using compatible RF receivers and controllers.
Example Applications
Automatically switch on single colour LED strip lighting when motion is detected using a compatible RF dimmer or RF LED controller.
Wirelessly trigger RGB LED strip controllers to activate feature lighting when someone enters a room or corridor.
Control RGBW or RGB+CCT LED strip systems wirelessly using compatible RF controllers, allowing motion-activated colour-changing lighting scenes.
Control compatible RF dimmable LED drivers without running additional control cabling between the sensor and lighting system.
Use the integrated 0-10V / 1-10V output to directly dim compatible commercial LED drivers and lighting systems commonly used in offices, warehouses, retail environments, showrooms, and commercial buildings.
Integrate the sensor into Zigbee 3.0 smart lighting systems for automation and smart building control applications.
The integrated AC relay output also allows direct switching of compatible mains-powered lighting loads up to the specified relay rating.
This multi-control design makes the sensor suitable for both simple standalone motion-controlled lighting and more advanced smart lighting automation projects.
Flexible Control Compatibility
RF 2.4GHz wireless control transmission
0-10V / 1-10V analogue dimming control
Zigbee 3.0 smart lighting communication
AC relay switching output
The RF wireless control function is designed primarily for compatible RF lighting controllers, RF dimmers, and RF dimmable LED drivers operating on the same RF protocol.
The 0-10V / 1-10V interface is compatible with many standard dimmable LED drivers supporting analogue dimming control.
Zigbee 3.0 compatibility may vary depending on the third-party hub, gateway, application, or automation platform used.
For best compatibility and reliability, use with tested compatible lighting controllers and RF devices is recommended.
Key Features
Microwave radar motion detection technology
Much higher sensitivity compared to standard PIR infrared sensors
360° ceiling detection coverage
RF 2.4GHz wireless control transmission
0-10V / 1-10V dimming output
Zigbee 3.0 smart lighting compatibility
Integrated AC relay switching output
Adjustable daylight threshold settings
Adjustable hold time settings
Suitable for smart lighting automation systems
Suitable for commercial and residential installations
Ideal for corridors, staircases, warehouses, offices, utility rooms and smart lighting projects
Technical Specifications
Input Voltage: 100-240VAC
Microwave Frequency: 10.525GHz
Detection Angle: 360°
Maximum Detection Area: Up to 20m diameter
Maximum Mounting Height: Up to 10m
Detection Speed: 0.5-3m/s
Relay Output: Max 4A
Dimming Output: 0-10V / 1-10V (Max 30mA)
Wireless Control: RF 2.4GHz
Smart Protocol: Zigbee 3.0
Operating Temperature: -20°C to +50°C
IP Rating: IP20
Installation Type: Ceiling Mounted
Installation & Compatibility Notes
This product is a sensor and control interface only and does not directly power LED strips or lighting loads beyond the specified relay output limits.
The sensor can be used with many compatible RF lighting controllers, RF LED dimmers, RF dimmable drivers, and compatible 0-10V / 1-10V LED drivers depending on the installation design.
Advanced users and system integrators may also integrate the product into compatible Zigbee 3.0 platforms at their own discretion.
For complex automation systems, larger projects, or advanced smart lighting integrations, customers are welcome to contact the Hi-Line support team for product guidance and compatibility assistance.
Please click the Attachments tab to download the full user manual and installation guide PDF.
Please click the Related Products tab to view compatible RF lighting controllers, dimmers, LED drivers, and other accessories commonly used with this product.
Final system design, configuration, wiring, and installation must always be carried out by a qualified installer or automation professional in accordance with local regulations.
