Dimmable LED Driver 100W 24V Premium Hybrid Series (Mains or 0/1-10V)

Key Features:

  • Hybrid Dimmable LED Driver High Power Factor
  • Works with Trailing Edge dimmer switches, 0-10V or potentiometer
  • Voltage: 24V DC Output
  • Power: 100 Watt
  • Voltage: 24V DC
  • Warranty: 5 Year Warranty
HL-PC10VT100W-24V-5Y
Out of Stock
£45.00
54.00
with VAT)




Hybrid dimmable 100 Watt 24V LED driver operates perfectly with trailing edge dimmers and can be used to dimming 24 Volts LED strips, controlled by standard wall dimmer switch powered by 240V AC or 0/1-10 Volts dimming systems.

It can operate with load ranging from 5% to 100% and the dimming range will be from less then 3% to 100%.

This dimmable driver can operate with trailing edge mains wall dimmer switches, 0/1-10V dimming systems or potentiometer.

We tested this dimmable driver with Lightwave smart dimmer & Varilight V-Pro series and it is compatible.

If you have a dimmer switch in mind and are unsure about compatibility, please email us for assistance.

It is recommended to calculate for an additional 20% overhead.

You can also read a little more about this driver over at our support page HERE.

5 Years Warranty

Dims: 27.5cm x 4.5cm x 2.5

______________________________

IMPORTANT NOTICE!

This device should be installed by a qualified electrician in accordance with the latest edition of the IEE Wiring Regulations and any applicable Building Regulations.

Brand
Hi-Line
Mains Dimming
Trailing Edge Dimmers
Power
100 W
IP Rating
IP40 (Non-waterproof)
Type
Hybrid Dimmable (Mains or 0/1-10V)
Voltage
24V DC
Voltage Type
Constant Voltage
Warranty
5 Years
