24V 30W hybrid dimmable LED driver, IP20, output terminals
24V 30W IP20 LED driver, mains input and push-fit terminals
24V 30W LED driver output, LED and dimmer push-fit terminals
  • New
24V 30W hybrid dimmable LED driver, IP20, output terminals
24V 30W IP20 LED driver, mains input and push-fit terminals
24V 30W LED driver output, LED and dimmer push-fit terminals

Dimmable LED Driver | 24V | 30W | Hybrid Series (Triac or 0/1-10V)

Key features:

  • Indoor hybrid dimmable LED driver, IP20
  • Leading edge and trailing edge, plus 0-10 V, 1-10 V, 10 V PWM and a resistor
  • 24 V DC constant voltage, 30 W, 1.25 A
  • Dims down to 0.1%
  • 5 year warranty
HL-10VT30W-24V-IP20

Need more than we have in stock?

We have 50 in stock, ready to dispatch. If you need more, increase the quantity and add it to the basket. Extra units go on back order: we will use incoming stock if any is still free, otherwise delivery is typically 30–45 days.
50 Items In stock
Next working day delivery
£20.83
(£
25.00
with VAT)
VAT excluded

Tags:


This is the 24 V, 30 W model in our indoor hybrid range. It is a constant-voltage supply for LED modules, in a compact IP20 case.

It dims from a mains wall dimmer on both leading-edge and trailing-edge circuits, and it also accepts 0-10 V, 1-10 V, 10 V PWM and a resistor from 0 to 100 kΩ. Hi-Line is confident it works with almost all mains dimmers of that kind. A test on the module you have is what confirms the match. If you are unsure, email us the dimmer details before you install.

Allow about 20% headroom above the LED load, and keep the load within 30 W.

Specification:

  • Input: 176-264 V AC, 50 Hz, 0.36 A maximum. Power factor above 0.55 at 230 V, full load
  • Output: 24 V DC, 1.25 A, 30 W maximum
  • Dimming down to 0.1%
  • Ambient temperature from -30 °C to 45 °C. Case temperature up to 90 °C
  • SELV, IP20, for indoor use. For LED modules only

Size: 131 x 31.5 x 24 mm. Weight: about 91 g. Efficiency: 87% typical at 24 V.

5 year warranty

Important. This driver should be installed by a qualified electrician in accordance with the current IET Wiring Regulations and any applicable Building Regulations.

The datasheet, the specifications and the related products on this page carry the rest of the detail.

Brand
Hi-Line
Power
30 W
IP Rating
IP20 (Non-waterproof)
Type
0-10V and 1-10V DIM
Hybrid Dimming (Mains & 0-10V)
mains-dimmable
Voltage
24V DC
Voltage Type
Standard Type
Warranty
5 Years
