Extra Warm White LED Strip 24V-7.2W/m- IP00-CRI90-SMD2835
High CRI, Ra >90
Extra Warm White
24 Volts DC, 7.2W per meter
Non waterproof IP00
5 meters roll (8mm)
5 Year Warranty
24V High CRI Ra >90 LED Strip Light 2400K extra warm white 60 LEDs/m - 5m roll
Non-Waterproof IP00, 24 Volts constant voltage extra warm white 2400K
High Bright LED Strip SMD2835 Chip, 60 LEDs, 7.2W per meter, 5 meters roll.
This is a high brightness LED strip, powered by Epistar SMD2835 LED chips (660 lm per meter / 60 LEDs)
The width of this LED strip is 8mm, height 3mm and can be cut at every 6 LEDs (10cm)
*5-year warranty:
*This LED tape should be installed according to our installation instructions. For more information on installing, please see the installation manual at the bottom of the page and to learn more about the 5 year warranty on offer, please refer to the following link:
All our LED Strips are dimmable. Please select a suitable PWM LED dimmer/controller.
______________________________
Please note that soldering is recommended for the connection of LED strips. However, if a solder free connection is preferred, Hi-Line’s solder free connectors offer the best solution currently available on the market.
______________________________
Price is for a 5 meters roll (300 LEDs), non waterproof (IP00), 7.2W/m CRI Ra>90 LED strip extra warm white 2200 to 2400K
Please note that the same extra warm white LED strip is available with a higher brightness with 14.4W per meter power consumption.
______________________________
Selection of the LED driver depending on the maximum LED strip length
The table below shows the maximum LED strip length, which can be operated with a given LED driver.
To consider the performance drop, which occurs in the power supply cable and the efficiency of the LED Driver, 20% was deducted from the maximum strip length in the table below.
Note that LED strips dimming is possible if the driver is used in combination with an LED controller. In such case LED driver is not required to be dimmable and brightness control (dimming) is still possible through the LED controller.
For more information about the installation of LED Strips, you can download below “Installation of LED Strips”.
- CIE Colour Space
- 3 SDCM
- Voltage
- 24V DC
- Colour
- Extra Warm White
- Power
- 7.2 W/m
- Brightness
- 660~720 Lm/m
- Number of LEDs per meter
- 60
- Rating
- IP00 (Non-waterproof)
- Colour Temperature (CCT)
- 2400K
- Colour rendering (CRI in ra)
- more than 90
- Width of strip
- 8mm
- Cutting length
- Every 6 LEDs (100mm)
- LED Strip Packing
- 5-meter roll
- Voltage Type
- Constant Voltage
- Warranty
- 5 Years
- Brand
- Hi-Line
- LED Chip
- SMD 2835
