High Efficiency 6000K pure white LED Strip 24V 14.4W/m IP00 160Lm/W

HL-LS2835HEB-96CW-IP00-24V

New product

Efficiency: >160Lm/W

Cool White LED strip, 6000K, 24V, IP00 (Non-Waterproof)

96 LEDs/m–14.4W/m–2300 Lm/m

5m roll–10mm width

High CRI - Ra>80

5 year warranty

More details

29 Items

Same Day Dispatch

£ 49,50 excl. VAT

£ 9,90 per meter

Add to wishlist

Data sheet

LED Chip SMD2835 High Efficacy
Voltage 24V DC
Colour Cool White
Power 14.4 W/m
Brightness 2300 Lm/m
Number of LEDs per meter 96
Rating IP00 (Non-waterproof)
Colour Temperature (CCT) 6000K
Colour rendering (CRI in ra) 80
Width of strip 10mm
Cutting length Every 8 LEDs (85mm)
LED Strip Packing 5-meter roll
Voltage Type Constant Voltage
Warranty 5 Years
Brand Hi-Line

More info

High Efficiency Pure White LED Strip 6000K, Efficacy >160 Lumens per watt

Energy saving LED strip version, will save more than 50% energy and have same brightness as 100lm/W LED strips

14.4W/m – 24V DC – 5m roll – 96 LEDs/m – IP00 (Non-Waterproof) – 2-wire cable (15cm on each side of the strip roll)

This is a very high efficiency LED strip powered by high-quality SMD2835 LED chips which generate a brightness of 160 LM/W (equivalent to 2300 Lm/m). Please note that 1.2 meters of this LED strip has the same or even higher brightness than a 4ft fluorescent tube.

CRI – all LED chips reach a value of Ra >80.

The strip can be cut every 8 LEDs (85mm). The width of the LED strip is 10mm.

Note: Whenever possible it is suggested to install this LED strip on an aluminium bar to ensure proper cooling and thus increasing the lifespan.

Fitted with an easy to install original 300 LSE 3M adhesive tape with excellent adhesion.

5-year warranty

______________________________

The high quality of Hi-Line LED strip products ensures low decay, which increases the LED strip's lifespan and assures that the high level of the brightness is kept constant throughout the LED strip's life.

Please do NOT connect more than 5 meters of a LED strip in series. A LED strip of more than 5 meters in length is overloaded due to the increased amount of current passing through, resulting in the damage of the PCB and the failure of the LED strip. Thus, when 5 meters of the LED strip is exceeded, it is suggested to connect the strip directly to the LED controller or driver using a 2-core cable.

Installation hints and tips for LED strips can be downloaded at the bottom of this web page.

_____________________________

The LED strip comes with a 15cm wire ending on each side of the strip roll.Therefore, no extra soldering is required if the roll should be cut into 2 different pieces (i.e. 3 meters + 2 meters).

Please note that soldering is recommended for the connection of LED strips. However, if a solder-free connection is preferred, Hi-Line’s solder-free connectors offer the best solution currently available on the market.

______________________________

All Hi-Line LED strips are dimmable. Please select a suitable PWM LED dimmer/controller to ensure the proper dimming of the LED strip.

______________________________

The stated price is for 1 x 5-meter roll LED strip (Cool White) with 480 SMD2835 high efficacy LEDs – IP00 (Non-Waterproof), 24V DC.

______________________________

Selection of the LED driver depending on the maximum LED strip length

The table below shows the maximum LED strip length, which can be operated with a given LED driver.

To consider the performance drop, which occurs in the power supply cable and the efficiency of the LED Driver, 20% was deducted from the maximum strip length in the table below.

Note that LED strips dimming is possible if the driver is used in combination with an LED controller. In such case LED driver is not required to be dimmable and brightness control (dimming) is still possible through the LED controller.
