Blue LED Strip 24V-14.4W/m- IP00-SMD2835

HL-LS2835H-60B-IP00-24V

New product

Blue colour, high bright

24 Volts DC, 14.4W per meter

Non-Waterproof IP00

5 meter roll (8mm)

3 years warranty

More details

24 Items

Same Day Dispatch

£ 32,00 excl. VAT

£ 6,40 per meter

Add to wishlist

Data sheet

LED Chip SMD 2835
Colour Blue
Voltage 24V DC
Power 14.4 W/m
Wavelength 456nm
Number of LEDs per meter 60
Rating IP00 (Non-waterproof)
Width of strip 8mm
Cutting length Every 6 LEDs (100mm)
LED Strip Packing 5-meter roll
Voltage Type Constant Voltage
Warranty 3 Years
Brand Hi-Line

More info

Blue 24V high grade LED Strip powered by SMD2835 LED chip, 14.4W per meter, 5 meters roll non-waterproof

The LED strip is 8mm wide and 3mm high. It can be cut at every 6 LEDs (10cm).

Non-Waterproof IP00, 24 Volts constant voltage blue ultra high bright LED strip SMD2835 Chip, 60 LEDs / 14.4W per meter, 5 meter roll with 3 years warranty.

This is an ultra high brightness LED strip, powered by Epistar SMD2835 LED chips.

Great for sign makers, cove lighting or any application that high brightness LED is necessary.

For longer life it is suggested to be installed on an aluminum bar for proper cooling.

All our LED strips are dimmable. Please select a suitable PWM LED dimmer/controller. The LED strip cannot be dimmed in any other way!

______________________________

Please note that soldering is recommended for the connection of LED strips. However, if a solder free connection is preferred, Hi-Line’s solder free connectors offer the best solution currently available on the market.

______________________________

Price is for a 5 meter roll (300 LEDs), Non-Waterproof (IP00)

______________________________

Selection of the LED driver depending on the maximum LED strip length

The table below shows the maximum LED strip length, which can be operated with a given LED driver.

To consider the performance drop, which occurs in the power supply cable and the efficiency of the LED Driver, 20% were deducted from the maximum strip length in the table below.

Note that LED strips dimming is possible if the driver is used in combination with an LED controller. In such case LED driver is not required to be dimmable and brightness control (dimming) is still possible through the LED controller.

____________________________

For more information about the installation of LED Strips, you can download the above PDF file: “Installation of LED Strips”.
