IP00 Red LED Strip 24V 9.6W/m 120 x SMD 3528 per meter, 5m roll

HL-LS3528-120R-IP00-24V

New product

24 Volts DC, IP00 LED strip

Powered by SMD3528 LED chip

120 LEDs/m, 9.6W/m

10mm width (3.5mm height)

5 meter roll, colour: red

5 Year Warranty

More details

70 Items

Same Day Dispatch

£ 40,00

£ 8,00 per Meter

Add to wishlist

Data sheet

LED Chip SMD 3528
CIE Colour Space 3 SDCM
Voltage 24V DC
Colour Red
Power 9.6 W/m
Wavelength 625nm
Number of LEDs per meter 120
Rating IP00 (Non-waterproof)
Width of strip 10mm
Height of strip 3.5mm
Cutting length Every 6 LEDs (50mm)
LED Strip Packing 5-meter roll
Voltage Type Constant Voltage
Warranty 5 Years
Brand Hi-Line

More info

Red colour Commercial high grade LED Strip / Tape high density 120 LEDs per meter

5 METER IP00 SMD 3528 LED STRIP LIGHT WITH 600 LEDS IN RED

Can be cut at every 6 LEDs (5cm), Width of the LED strip is 10mm.

24 Volts DC, IP00 LED strip powered by SMD3528 LED chip, 120LEDs/m, 9.6W/m, 5 meter roll, colour: red

The quality of this product is superior!

All our LED strips are dimmable. Please select a suitable PWM LED dimmer/controller. The LED strip cannot be dimmed in any other way!

Fitted with an easy to install original 3M adhesive tape with excellent adhesion (identified by a red protective strip on the adhesive side).

______________________________

Please note that soldering is recommended for the connection of LED strips. However, if a solder free connection is preferred, Hi-Line’s solder free connectors offer the best solution currently available on the market.

______________________________

Our price is for 1 x 5 meters roll (600 LEDS) single colour LED Strip (Red) - IP00

*5-year warranty:

*This LED tape should be installed according to our installation instructions. For more information on installing, please see the installation manual at the bottom of the page and to learn more about the 5 year warranty on offer, please refer to the following link:

LED Strip Warranty Guide

______________________________

Selection of the LED driver depending on the maximum LED strip length

The table below shows the maximum LED strip length, which can be operated with a given LED driver.

To consider performance drop, which occurs in the power supply cable, and to consider the efficiency of the LED Driver, 20% is deducted from the maximum strip length in the table below.

Note that LED strip dimming is possible if the driver is used in combination with an LED controller. In such a case, the LED driver is not required to be dimmable and brightness control (dimming) is still possible through the LED controller.

____________________________

For more information about the installation of LED Strips, you can download the above PDF file: “Installation of LED Strips”.
