Dimmable 60W LED Driver 24V Hybrid Premium Series (Mains or 0/1-10V)

Hybrid Dimmable LED Driver High Power Factor

Works with Trailing Edge dimmer switches, 0-10V or potentiometer

24V DC Output

60 Watt / 24V

Warranty: 5 Years

HL-PC10VT60W-24V-5Y
30 Items In stock
Same Day Dispatch
£36.50
VAT excluded

Secure Checkout



Hybrid dimmable 60 Watt 24V LED driver operates perfectly with trailing edge dimmers and can be used to dimming 24 Volts LED strips, controlled by standard wall dimmer switch powered by 240V AC or 0/1-10 Volts dimming systems.

It can operate with load ranging from 5% to 100% and the dimming range will be from less then 3% to 100%.

This dimmable driver can operate with trailing edge mains wall dimmer switches, 0/1-10V dimming systems or potentiometer.

We tested this dimmable driver with Lightwave smart dimmer & Varilight V-Pro series and it is compatible.

If you have a dimmer switch in mind and are unsure about compatibility, please email us for assistance.

It is recommended to calculate for an additional 20% overhead.

You can also read a little more about this driver over at our support page HERE.

L 179mm x W 58mm x H 25mm

5 Years Warranty

______________________________

IMPORTANT NOTICE!

This device should be installed by a qualified electrician in accordance with the latest edition of the IEE Wiring Regulations and any applicable Building Regulations.

Voltage
24V DC
Mains Dimming
Trailing Edge Dimmers
Power
60 W
Rating
IP40 (Non-waterproof)
Type
Hybrid Dimmable (Mains or 0/1-10V)
Voltage Type
Constant Voltage
Warranty
5 Years
Brand
Hi-Line
