Wireless Single Colour LED Strip dimmer

HL-SC1ZRX01

New product

Wireless 1 Zone LED Controller

Built-In Sync function

4CH /4 outputs, 5A max each

12~36V Input / Output

Remote Learning Key

5 years Warranty

More details

39 Items

Same Day Dispatch

£ 35,00 excl. VAT

Add to wishlist

Data sheet

Type Single colour controller
Type of control Radio Frequency (RF)
Warranty 5 Years
Brand Hi-Line

More info

RF Wireless single colour LED controller, constant voltage output to be used with LED strip lighting.

Perfect match for our single zone LED remote control model "SC1ZTX01" (sold separately).

Several controllers can be assigned to operate with one remote control and LED strips will still be in sync.
It comes with a learning button for quick and easy link with the remote control.

Single Zone / 4 outputs (used for splitting LED Strip load), 5 Amps per channel maximum load.
Can operate with wide range of input voltages, between 12 to 36 Volts DC, this makes the product ideal to be used with either 12 or 24 Volts LED tapes.

Standard output configuration of this controller is 4 channels of max. 5A each but you can bridge the 2 channels and in this way you will have 2 x 10A outputs. All outputs (either if using 2 or 4CH) will still operate on the same zone/area and more than one single colour LED controllers can be paired with just one remote control. If the 4 outputs are not bridged, you can drive MAX. of 7m of 14.4W/m LED strip per output (5A/24V) but if you bridge the 2 x 5A outputs as per diagram shown below then you can drive up to maximum of 14m per bridged output (14m x 2). It is suggested not to exceed 15m of high brightness 14.4W/m LED strip in total per wireless controller.

An extra LED Driver will be necessary to provide the DC voltage according to the application and design. It is strongly recommended using only switch mode power supplies ("LED Drivers")!

Bridge Configuration diagram for 2 x 10A output
Note: You cannot bridge all 4 channels!

Please check also our single and RGBW colour LED controller here which can only be used with multi-zone

remote control for single colour LED strips or with either the 4 or the 6 zones RGBW remote.

We will be happy to provide technical support and help you design your own configuration, please contact us.
