All in One LED Controller & RF Remote control Kit - 5CH PWM & SPI

At Hi-Line Lighting, we pride ourselves on our unwavering commitment to excellence, which is evident not only in our own product range but also in the carefully curated selection of products we offer from trusted partners. We directly import the genuine SP630E LED Controller Kit, ensuring authenticity and quality, unlike similar products from unknown sources.

Understanding the need for a comprehensive suite of products to meet the diverse requirements of your projects, we introduce this product as a part of our selected offerings. Although not designed or manufactured by Hi-Line, this product has been subjected to thorough testing and approval by our expert engineering team, ensuring it adheres to our stringent quality and value standards. This reflects our dedication to providing our customers with partner economy products that offer exceptional value for money.

The SP630E LED controller boasts compatibility with a myriad of LED types. It is adept at working with 1/2/3/4/5CH W/CCT/RGB/RGBW/RGBCCT PWM, addressable Pixel LED strips, Neon Flex, and even addressable + PWM combined LEDs.

Supported LED Strip Types include SPI IC chip LED strip + PWM common anode, as well as addressable RGBW LED Strips with the SK6812 chip among others (detailed in the datasheet).

RF LED Controller Features:

1. High-efficiency, low power consumption 2.4G RF controller.
2. Supports 12 varieties of LED light strips.
3. Enables App control alongside 2.4G touch remote control.
4. Offers zone-control (up to 4 zones) or unified control options with the remote.
5. Allows setting of various on/off animations and default power-on states.
6. Facilitates modification of device name, colour order correction, and timer settings.
7. Features three music capture modes: cell phone microphone, player streaming, and onboard microphone.
8. Includes five main control pages in the App: dynamic, static, music, custom, and setting, with LED types dictating App page content.
9. Operates on a DC5V-24V working voltage, with the 2.4G Remote Control requiring 3V (Controller voltage contingent on LED strip).
10. The PWM Single Channel's maximum output current is 6A, with a total maximum of 12A across all channels.
11. Supported LED Strip Types (except Common anode strips) include SPI addressable RGBW LED Strips using SK6812 chip among others (maximum pixel 600).

The SP630E is compatible with 2.4G touch remote controls and 2.4G touch 86-type panels, offering four varieties of each; different LED types can be matched with corresponding remote control and panel types within the same product series. For further details, refer to the datasheet, particularly pages 12/13.

RF Remote Control Features:

1. Utilizes 2.4G wireless remote control technology, characterized by low power consumption, long transmission range, and strong anti-interference capabilities.
2. Features touch control for high sensitivity, consistency, and reliability.
3. Supports one-to-many and multi-to-many controls, allowing a single remote to control multiple controllers and each controller to bind up to 5 remotes.
4. Provides options for unified and 4-zone control.

App Compatibility:

• The addressable LED controller supports App control for both iOS and Android devices.
• Requires iOS 10.0 or higher for Apple devices and Android 4.4 or higher for Android devices.
• The "BanlanX" App can be found in the App Store or Google Play, or the QR code in the datasheet can be scanned for download and installation.

This controller can efficiently drive a wide range of Common Anode LED Strips including 1 Channel PWM Single colour, 2 Channel PWM CCT, 3 Channel PWM RGB, 4 channel PWM RGBW, and 5 channel RGB+CCT. It is also compatible with various types of SPI digital pixel addressable LED strips and Neon Flex, such as SPI Single Colour, SPI CCT, SPI RGB, SPI RGBW, SPI RGBCCT, SPI RGB+1CH PWM Single Colour, and SPI RGB+2CH PWM CCT.
